Table 40: Mains Cable Size Recommendations, 380–500 V (continued)
Model
code
Frame I
N
[A]
Cable [mm
2
]
Maximum
cable size
[mm
2
]
Maximum
number
of mains
cables
(1)
Hole size of
the mains
terminal
[mm]
Number of
grounding
holes on PE
busbar
Hole size
of the
grounding
terminal
[mm]
iC7-60EA3A
05-385A
325 Cu 1 x (3x150+70)
Al 2 x (3x95+29 Cu)
240 Cu/Al 2
(4)
Ø13.5
(5)
4 Ø10.5
iC7-60EA3A
05-480A
403 Cu 2 x (3x95+ 50)
Al 2 x (3x120+41
Cu)
240 Cu/Al 2
(4)
Ø13.5
(5)
4 Ø10.5
iC7-60EA3A
05-590A
AE10 +
IE10
(3)
508 Cu 2 x (3x120+70)
Al 2 x (3x150+41
Cu)
240 Cu/Al 2
(4)
Ø13.5
(5)
4 Ø10.5
iC7-60EA3A
05-658A
571 Cu 2 x (3x150+70)
Al 3 x (3x120+41
Cu)
240 Cu/Al 4 Ø13 5 Ø10.5
iC7-60EA3A
05-730A
647 Cu 3 x (3x120+70)
Al 3 x (3x150+70
Cu)
240 Cu/Al 4 Ø13 5 Ø10.5
iC7-60EA3A
05-820A
728 Cu 3 x (3x120+70)
Al 4 x (3x120+41
Cu)
240 Cu/Al 4 Ø13 5 Ø10.5
iC7-60EA3A
05-880A
AE11 +
IE11
809 Cu 3 x (3x150+70)
Al 4 x (3x120+41
Cu)
240 Cu/Al 4 Ø13 5 Ø10.5
iC7-60EA3A
05-1000
905 Cu 4 x (3x120+70)
Al 4 x (3x150+70
Cu)
240 Cu/Al 6 Ø13 5 Ø10.5
iC7-60EA3A
05-1100
2 x AE10 +
2 x IE10
1018 Cu 4 x (3x150+70)
Al 4 x (3x185+57
Cu)
240 Cu/Al 6 Ø13 5 Ø10.5
iC7-60EA3A
05-1260
1148 Cu 6 x (3x95+50)
Al 6 x (3x120+41
Cu)
240 Cu/Al 8 Ø13 8 Ø10.5
iC7-60EA3A
05-1450
1293 Cu 6 x (3x120+70)
Al 6 x (3x150+70
Cu)
240 Cu/Al 8 Ø13 8 Ø10.5
iC7-60EA3A
05-1710
2 x AE11 +
2 x IE11
1453 Cu 6 x (3x150+70)
Al 6 x (3x185+57
Cu)
240 Cu/Al 8 Ø13 8 Ø10.5
1) Cable lugs installed on both sides of the fixing hole
2) With copper cables, use copper lugs. With aluminum cables, use bimetallic lugs.
