1) When button position 1 is pressed you will enter the alarm list. The active alarms will
have the symbol with yellow light flashing.
2) Button position 2 is for the manual advancement of the film (manually turns the fin
wheels).
3) Position 3 is the product counter, the number of bags is the figure written inside the
rectangle.
4) Position 4 is the machine speed. By pressing the + or – the machine speed can be
increased or decreased.
5) When button position 5 is pressed you will enter the page that gives you the fin wheels
and jaw temperatures.
6) When the button position 6 is pressed you will enter in the page block notes and optional.
7) Position 7 is the bag length expressed in millimeters, the active bag length is the value in
the green rectangle. To change the bag length proceed as follows:
Press button position 7.
Open the numerical table and digit the desired bag length.
Confirm the new bag length by pressing Enter.
8) To pass on to the recipe page press button position 8.
9) Position 9 is to show you the name and recipe number of the active recipe.
10) Button to open / close the wheels.
11-13) Buttons showing the active film reel holder
12) Button to open / close the rubber roll. GREEN = close, GRAY = open
14) Button to discharge the machine.
