Digi Connect IT 4 User Manual

Routing IP routing
Digi Connect IT® 4 User Guide
266
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Add a new routing policy:
(config)> add network route policy end
(config network route policy 0)>
New route policies are enabled by default. To disable:
(config network route policy 0)> enable false
(config network route policy 0)>
4. (Optional) Set the label that will be used to identify this route policy:
(config network route policy 0)> label "New route policy"
(config network route policy 0)>
5. Set the interface on the Connect IT 4 device that will be used with this route policy:
a. Use the ? to determine available interfaces:
(config network route policy 0)> interface ?
Interface: The network interface used to reach the destination. Packets
that satisfy the matching criteria will be routed through this
interface. If the interface has a gateway then it will be used as the
next hop.
Format:
/network/interface/defaultip
/network/interface/defaultlinklocal
/network/interface/eth1
/network/interface/eth2
/network/interface/loopback
Current value:
(config network route policy 0)> interface
b. Set the interface. For example:
(config network route policy 0)> interface /network/interface/wan
(config network route policy 0)>
6. (Optional) Enable exclusive to configure the policy to drop packets that match the policy when
the gateway interface is disconnected, rather than forwarded through other interfaces:
(config network route policy 0)> exclusive true
(config network route policy 0)>
