Digi Connect IT 4 User Manual

Virtual Private Networks (VPN) Generic Routing Encapsulation (GRE)
Digi Connect IT® 4 User Guide
413
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Network > Interfaces.
4. For Add Interface, type a name for the GRE loopback endpoint interface and click .
5. Enable the interface.
New interfaces are enabled by default. To disable, toggle off Enable.
6. For Interface type, select Ethernet.
7. For Zone, select Internal.
8. For Device, select Ethernet: Loopback.
9. Click to expand IPv4.
10. For Address, enter the IP address and subnet mask of the local GRE endpoint, for example
10.10.1.1/24.
11. Click Apply to save the configuration and apply the change.
Command line
1. Select the device in Remote Manager and click Actions > Open Console, or log into the
Connect IT 4 local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Add the GRE endpoint interface. For example, to add an interface named gre_endpoint:
(config)> add network interface gre_interface
(config network interface gre_interface)>
4. Set the interface zone to internal:
(config network interface gre_interface)> zone internal
(config network interface gre_interface)>
5. Set the interface device to loopback:
(config network interface gre_interface)> device /network/device/loopback
(config network interface gre_interface)>
6. Set the IP address and subnet mask of the local GRE endpoint. For example, to set the local
GREendpoint's IP address and subnet mask to 10.10.1.1/24:
