Digital Projection Titan Quad / 800 / 930 Series POSITIONING THE IMAGE Reference Guide
132
Rev H October 2013
Maximum offset range
The maximum offset range available with no distortion or vignetting is dependent on which lens is used. Shifting the lens beyond its
undistorted limits may be physically possible, however you may experience some vignetting or distortion.
for WUXGA projectors vertical
(pixels)
horizontal
(pixels)
vertical
(frames)
horizontal
(frames)
0.67 : 1 xed lens ±130 ±85 ±0.108 ±0.044
1.16 - 1.49 : 1 zoom lens ±490 ±360 ±0.408 ±0.188
1.50 - 2.17 : 1, 1.72 - 2.71 : 1 and 2.15 - 3.36 : 1 zoom lenses ±285 ±200 ±0.237 ±0.104
1.12 : 1 xed lenses and all other zoom lenses +680 / -540 ±360 +0.567 / - 0.45 ±0.188
for 1080p projectors vertical
(pixels)
horizontal
(pixels)
vertical
(frames)
horizontal
(frames)
0.67 : 1 xed lens ±190 ±120 ±0.176 ±0.063
1.16 - 1.49 : 1 zoom lens +550 / -540 ±360 +0.509 / - 0.5 ±0.188
1.50 - 2.17 : 1, 1.72 - 2.71 : 1 and 2.15 - 3.36 : 1 zoom lenses ±345 ±229 ±0.319 ±0.119
1.12 : 1 xed lenses and all other zoom lenses +740 / -540 ±360 +0.685 / - 0.5 ±0.188
for SX+ projectors vertical
(pixels)
horizontal
(pixels)
vertical
(frames)
horizontal
(frames)
0.73 : 1 xed lens ±120 ±95 ±0.114 ±0.068
1.26 - 1.61 : 1 zoom lens ±380 ±280 ±0.362 ±0.2
1.63 - 2.35 : 1, 1.86 - 2.93 : 1 and 2.33 - 3.64 : 1 zoom lenses ±232 ±187 ±0.221 ±0.134
1.21 : 1 xed lenses and all other zoom lenses +525 / -420 ±280 +0.5 / - 0.4 ±0.2
Notes
For more information on shifting
the lens, see Lens menu in the
Operating Guide
