Digital Projection Titan Quad / 800 / 930 Series APPENDIX C: SUPPORTED SIGNAL INPUT MODES Reference Guide
170
Rev H October 2013
Appendix C: Supported Signal Input Modes
2D input modes
Standard
Resolution
Vertical Frequency
(Hz)
Total number of lines
Horizontal
Frequency (kHz)
Composite 1 & 2 /
S-Video
Component
DVI-A / VGA
DVI-D / HDMI
3G-SDI
SDTV 480i 720 x 480 59.94 525 15.73
  
576i 720 x 576 50.00 625 15.63
  
EDTV 480p59 720 x 480 59.94 525 31.47
  
480p60 720 x 480 60.00 525 31.50
  
576p50 720 x 576 50.00 625 31.25
  
HDTV 720p50 1280 x 720 50.00 750 37.50
  
720p59 1280 x 720 59.94 750 44.96
  
720p60 1280 x 720 60.00 750 45.00
  
1080s23 1920 x 1080 23.98 1125 26.97
  
1080p23 1920 x 1080 23.98 1125 26.97
  
1080s24 1920 x 1080 24.00 1125 27.00
  
1080p24 1920 x 1080 24.00 1125 27.00
  
1080p25 1920 x 1080 25.00 1125 28.13
  
1080p29 1920 x 1080 29.97 1125 33.72
  
1080p30 1920 x 1080 30.00 1125 33.75
  
1080i50 1920 x 1080 50.00 1125 28.13
  
1080p50 1920 x 1080 50.00 1125 56.25
  
1080i59 1920 x 1080 59.94 1125 33.72
  
1080p59 1920 x 1080 59.94 1125 67.43
  
