Digital Projection Titan Quad / 800 / 930 Series APPENDIX D: MENU MAP Reference Guide
177
Rev H October 2013
Main Menu Sub Menus
Geometry
Aspect Ratio Source, Fill Display, Fill & Crop, Anamorphic, TheaterScope
Overscan (slider, value range 0 ~ 3)
Size & Position
Enable Off, On
Setting Global, Per Mode
H Position (slider, value range -100 ~ 100 [0])
V Position (slider, value range -100 ~ 100 [0])
H Size (slider, value range 25 ~ 400 [100])
Aspect Lock On, Off
V Size (slider, value range 25 ~ 400 [100])
Reset (command)
Blanking
Enable Off, On
Top (slider, value range 0 ~ 100 [0])
Bottom (slider, value range 0 ~ 100 [0])
Left (slider, value range 0 ~ 255 [0])
Right (slider, value range 0 ~ 255 [0])
Geometry Engine Off, Keystone, Cornerstone, Rotation, Warp
H Keystone (slider, value range -50 ~ 50 [0])
V Keystone (slider, value range -50 ~ 50 [0])
Pincushion / Barrel (slider, value range -30 ~ 30 [0])
Rotation (slider, value range -90 ~ 90 [0])
Warp Map Off, 1, 2, 3, 4, 5, 6, 7, 8
Cornerstone
Upper Left X (slider, value range -500 ~ 500 [0])
Upper Left Y (slider, value range -500 ~ 500 [0])
Upper Right X (slider, value range -500 ~ 500 [0])
Upper Right Y (slider, value range -500 ~ 500 [0])
Lower Left X (slider, value range -500 ~ 500 [0])
Lower Left Y (slider, value range -500 ~ 500 [0])
Lower Right X (slider, value range -500 ~ 500 [0])
Lower Right Y (slider, value range -500 ~ 500 [0])
Notes
Some of the information in this menu
map is summarised. See the actual
menu on the projector for full detail.
The underlined text represents
the factory default value for each
setting.
