Digital Projection Titan 930 User Manual

Digital Projection Titan Quad / 800 / 930 Series APPENDIX A: LENS PART NUMBERS Reference Guide
147
Rev H October 2013
Appendix A: Lens Part Numbers
Throw ratios
for 1080p and WUXGA
projectors
Throw ratios
for SX+ projectors
Lens extension
(±2%)
Throw distance range Part number for
High Brightness
lens
Part number for
High Contrast
lens
0.67 : 1 xed lens 0.73 : 1 xed lens 204 mm (8.0 in.) 1.1 - 10 m (3.6 - 32.8 ft) 105-607 107-195
1.12 : 1 xed lens (3 - 15 m) 1.21 : 1 (3 - 15 m) xed lens 268 mm (10.6 in.) 3 - 15 m (9.8 - 49.2 ft) 105-608 105-608
1.12 : 1 xed lens (1.2 - 2 m) 1.21 : 1 (1.2 - 2.0 m) xed lens 268 mm (10.6 in.) 1.2 - 2 m (3.9 - 6.6 ft) 105-609 105-609
1.16 - 1.49 : 1 zoom lens 1.26 - 1.61 : 1 zoom lens 226 mm (8.9 in.) 3 - 15 m (9.8 - 49.2 ft) 109-236 109-359
1.39 - 1.87 : 1 zoom lens 1.5 - 2.02 : 1 zoom lens 194 mm (7.6 in.) 4 - 24 m (13.1 - 78.7 ft) 105-610 107-196
1.87 - 2.56 : 1 zoom lens 2.02 - 2.77 : 1 zoom lens 159 mm (6.3 in.) 4 - 24 m (13.1 - 78.7 ft) 105-611 107-197
2.56 - 4.17 : 1 zoom lens 2.77 - 4.51 : 1 zoom lens 145 mm (5.7 in.) 9.1 - 45 m (29.9 - 147.6 ft) 105-612 107-198
4.17 - 6.95 : 1 zoom lens 4.51 - 7.53 : 1 zoom lens 129 mm (5.1 in.) 12 - 80 m (39.4 - 262.5 ft) 105-613 107-199
6.93 - 10.34 : 1 zoom lens 7.5 - 11.2 : 1 zoom lens 179 mm (7.0 in.) 12 - 80 m (39.4 - 262.5 ft) 109-235 109-358
1.50 - 2.17 : 1 zoom lens 1.63 - 2.35 : 1 zoom lens 184 mm (7.2 in.) 5 - 25 m (16.4 - 82 ft) 114-143 n/a
1.72 - 2.71 : 1 zoom lens 1.86 - 2.93 : 1 zoom lens 178 mm (7.0 in.) 5 - 25 m (16.4 - 82 ft) 114-144 n/a
2.15 - 3.36 : 1 zoom lens 2.33 - 2.64 : 1 zoom lens 180 mm (7.1 in.) 5 - 25 m (16.4 - 82 ft) 114-145 n/a
Notes
The throw ratios given here apply
only when the image lls the width
of the DMD.
For images that do not ll the width
of the DMD, the throw ratio needs to
be recalculated using a throw ratio
correction (TRC).
For further information, see
Choosing A Lens and Appendix B:
Lens Charts in this guide.
Throw distance calculations are
based on the distance from the outer
end of the lens, which will vary from
lens to lens.
The High Brightness lenses are
recommended for the standard
models, for maximum light output.
The High Contrast lenses are
recommended for the Ultra Contrast
models, for maximum contrast.
Lens extension is measured when
the lens is focussed at innity,
and fully extended. At other focus
settings, the extension could be up
to 10mm less.
