Using The Projector
Main menu
• Input Selection
Select an input source from the drop-down list.
• Test Pattern
Set Input Selection to Test pattern and then select a test pattern from the drop-down list.
• Lens, Image, Color and Geometry
Open these sub-menus to access various picture and screen settings.
• Edge Blend / PIP
PIP and Edge Blend are mutually exclusive modes of operation. When the projector is in Edge
Blend mode (as shown in the picture), PIP is not available, and vice versa.
• 3D
Access 3D settings.
• Lamps
Select lamp conguration and adjust lamp power.
• Setup
Adjust InputConguration, Network, On Screen Display and System settings.
• Information
View your current conguration.
Notes
See also Using The Menus earlier
in this guide and Appendix D:
Menu Map in the Reference Guide.
Main Menu
You can also select an input source
by pressing the following buttons on
the remote control: 1 to 9 for inputs
1 to 9, 10+ for input 10 and # for
input 11.
Inputs 9, 10 and 11 are not available
on 2D models.
Test patterns are subject to image
controls, so brightness, contrast
etc. will affect their appearance on
screen.
Do not use the provided test
patterns for ColorMax.
You can upload custom test patterns
using a network connection - see
Web Configuration Utility in the
Remote Communications Guide.
The 3D menu is not available with
2D projectors.
