Digital Projection Titan Quad / 800 / 930 Series ASPECT RATIOS EXPLAINED Reference Guide
140
Rev H October 2013
Aspect ratio examples for DMD™ resolution WUXGA
Source: 4:3
1
Unused screen areas
2
Cropped parts of the image
Notes
Aspect Ratio: Source Aspect Ratio: Fill Display
Aspect Ratio: Fill & Crop
Aspect Ratio: Anamorphic
2
1
1
1
1
2
