Digital Projection Titan Quad / 800 / 930 Series APPENDIX C: SUPPORTED SIGNAL INPUT MODES Reference Guide
173
Rev H October 2013
3D input modes
Standard
Resolution
Vertical
Frequency
(Hz)
Total number
of lines
Horizontal
Frequency
(kHz)
Main / DVI
Sub / HDMI
Dual Pipe
DVI-A / VGA /
Component
DVI-D / HDMI
3G-SDI
720p50 Frame Packing 1280 x 720 50.00 1470 37.50
 
720p59 Frame Packing 1280 x 720 59.94 1470 44.96
 
720p60 Frame Packing 1280 x 720 60.00 1470 45.00
 
720p50 Top-and-Bottom 1280 x 720 50.00 750 37.50
    
720p59 Top-and-Bottom 1280 x 720 59.94 750 44.96
    
720p60 Top-and-Bottom 1280 x 720 60.00 750 45.00
    
1080p23 Frame Packing 1920 x 1080 23.98 2205 26.97
 
1080p24 Frame Packing 1920 x 1080 24.00 2205 27.00
 
1080i50 Side-by-Side (Half) 1920 x 1080 50.00 1125 56.25
    
1080i59 Side-by-Side (Half) 1920 x 1080 59.94 1125 67.43
    
1080i60 Side-by-Side (Half) 1920 x 1080 60.00 1125 67.50
    
1080p50 Side-by-Side (Half) 1920 x 1080 50.00 1125 56.25
    
1080p59 Side-by-Side (Half) 1920 x 1080 59.94 1125 67.43
    
1080p60 Side-by-Side (Half) 1920 x 1080 60.00 1125 67.50
    
1080p50 Top-and-Bottom 1920 x 1080 50.00 1125 56.25
    
1080p59 Top-and-Bottom 1920 x 1080 59.94 1125 67.43
    
1080p60 Top-and-Bottom 1920 x 1080 60.00 1125 67.50
    
1080p50 Frame Sequential 1920 x 1080 50.00 1125 56.25
    
1080p59 Frame Sequential 1920 x 1080 59.94 1125 67.43
    
1080p60 Frame Sequential 1920 x 1080 60.00 1125 67.50
    
1080p23 Dual Pipe 1920 x 1080 23.98 1125 26.97

1080p24 Dual Pipe 1920 x 1080 24.00 1125 27.00

Notes
3D may not be present on some
models.
Only the Sub / HDMI input supports
HDMI 1.4 3D formats.
Geometric correction is only
available when using frame
sequential formats on the DVI-A /
VGA / Component / DVI-D / HDMI /
3G-SDI inputs.
