Digital Projection Titan Quad / 800 / 930 Series APPENDIX C: SUPPORTED SIGNAL INPUT MODES Reference Guide
174
Rev H October 2013
Standard
Resolution
Vertical
Frequency
(Hz)
Total number
of lines
Horizontal
Frequency
(kHz)
Main / DVI
Sub / HDMI
Dual Pipe
DVI-A / VGA /
Component
DVI-D / HDMI
3G-SDI
1080p25 Dual Pipe 1920 x 1080 25.00 1125 28.13

1080p30 Dual Pipe 1920 x 1080 30.00 1125 33.75

1080p50 Dual Pipe 1920 x 1080 50.00 1125 56.25

1080p59 Dual Pipe 1920 x 1080 59.94 1125 67.43

1080p60 Dual Pipe 1920 x 1080 60.00 1125 67.50

Notes
3D may not be present on some
models.
Only the Sub / HDMI input supports
HDMI 1.4 3D formats.
Geometric correction is only
available when using frame
sequential formats on the DVI-A /
VGA / Component / DVI-D / HDMI /
3G-SDI inputs.
