Configuring the ECLYPSE Wi-Fi Adapter Wireless Networks

102 ECLYPSE User Guide

Signal strength is measured in negative units where the stronger the signal, the

closer it is to zero. A weaker signal strength will have a more negative number.

For example, a receive signal strength of -35 dBm is much stronger than a receive

signal strength of -70 dBm.
