ECLYPSE Web Interface
ECLYPSE User Guide 77
BACnet Settings
This is where the BACnet interface parameters are set.
General
This sets the controller’s BACnet network parameters.
Figure 8-7: General BACnet Settings
Set a descriptive name by which this controller will be known to
other BACnet objects.
Each controller on a BACnet intra-network (the entire BACnet BAS
network) must have a unique Device ID. Refer to the Network Guide
for more information.
The current controller’s physical location. This is exposed on the
BACnet network as a device object property.
A description of the controllers function. This is exposed on the
BACnet network as a device object property.
The maximum amount of time the controller will wait for an
acknowledgement response following a confirmed request sent to a
BACnet device before re-sending the request again or moving onto
the next request. This property is exposed on the BACnet network
as a device object property.
The maximum amount of time the controller will wait for an
acknowledgement response following a confirmed segmented
request sent to a BACnet device before re-sending the segmented
request again or moving onto the next request. This property is
exposed on the BACnet network as a device object property.
This sets the number of times to retry a confirmed request when no
acknowledgement response has been received. This property is
exposed on the BACnet network as a device object property.
