ECLYPSE Web Interface
ECLYPSE User Guide 89
Figure 8-19: Using the Network’s RADIUS Server for User Authentication
Management
The port values of 1812 for authentication and 1813 for accounting are RADIUS standard
port numbers. However, other port numbers may be used. No matter which port numbers
are used, make sure that the port numbers are unused by other services on this controller
and that both the RADIUS server and the RADIUS clients use the same port number values.
See also ECLYPSE IP Network Port Numbers and Protocols on page 28.
The IP address of the remote RADIUS server. This can be the IP
address of an ECY series controller that has Authentication set to
Local, or a suitably-configured RADIUS server on an EC-Net
AX
/
EC-BOS
AX
station.
This is the port on which authentication requests are made.
This is the port on which accounting request are made. This is only
used to receive accounting requests from other RADIUS servers.
This is an internal port used to proxy requests between a local
server and a remote server.
This is an encryption key that devices use to encrypt and decrypt
user authentication credentials that are sent between devices. The
shared key should be a long string of up 32 alphanumeric characters
and symbols that would be difficult to guess. For example,
he^sg3iq6pg2*gqw@89hsm,wz[
If EC-Net
AX
is the remote RADIUS server, the same value must be
copied to the Shared Secret parameter in the RadiusService.
Click to copy the shared key to the clipboard.
