Vigor2760 Series User’s Guide
96
Delete
Remove the selected NAT profile.
Reset
Click it to rest to factory default settings.
Refresh
Click it to refresh the web page.
Enable
Display the activation status for such interface.
Enable – The profile is activated.
Disable –The profile is not activated.
Name
Display the profile name for the static route.
Destination IP
Address/Mask
Display the destination address/mask of the static route.
Interface
Display the interface that such static route uses.
Gateway
Display the IP address receiving the packets from destination
IP address/mask.
To add a static route profile, please do the following:
1. Click Add.
2. The following page appears.
Available parameters are listed below:
Item Description
Enable
Check the box to enable such profile.
Name
Type a name for such profile.
Destination IP
Address/Mask
Type the IP address of the destination. All the packets into
such IP address will be forwarded to the gateway specified in
To Next Page
