Vigor2760 Series User’s Guide
80
Cancel
Click it to return to previous web page.
3. After finished the settings above, click Apply to save the settings then click Cancel to
return to previous page.
4
4
.
.
1
1
.
.
1
1
.
.
1
1
2
2
W
W
A
A
N
N
D
D
S
S
L
L
M
M
o
o
d
d
e
e
The DSL mode tab is used to configure which xDSL mode is used by the router. Please
configure this according to the DSL type provided by the ISP. The DSL mode configured in
the profiles under the DSL Mode tab will work only if they match the configurations here.
Available parameters are listed below:
Item Description
Physical Type
Use the drop down list to specify the physical type of the
WAN interface.
Auto: The router will detect which mode that the ISP is
using. Usually it might be ADSL1/2/2+ or VDSL2.
ADSL AnnexJ: The DSL physical type can be ADSL
Annex J.
ADSL Multimode: The DSL physical type can be ADSL,
ADSL2 or ADSL2+.
VDSL2 only: The DSL interface is fixed with VDSL2 only.
DSL Debug Mode
Check it to enable the debug mode to find out the problem
via DSL synchronization.
Using custom modem
code
Different countries adopt different modem codes. If the
default DSL modem firmware (offered by DrayTek) is not
suitable for your request, simply check this box to replace
the DSL modem firmware to get the suitable modem code.
DSL firmware for upload – Choose the DSL module
firmware you want to upload to Vigor router.
Apply
Click it to save the settings.
Clear
Click it to remove the modification of the web page.
