Vigor2760 Series User’s Guide
219
or there is no answer of the connected phone.
Call Forward [DeAct]
Dial the number typed in this field to release the call forward
function.
Do Not Disturb [Act]
Dial the number typed in this field to invoke the function of
DND.
Do Not Distrub [DeAct]
Dial the number typed in this field to release the DND
function.
Hide Caller ID [ACT]
Dial the number typed in this field to make your phone
number (ID) not displayed on the display panel of remote
end.
Hide Caller ID [DeACT]
Dial the number typed in this field to release this function.
Call Waiting [ACT]
Dial the number typed in this field to make all the incoming
calls waiting for your answer.
Call Waiting [DeACT]
Dial the number typed in this field to release this function.
Apply
Click it to save the settings.
Clear
Click it to remove the modification of the web page.
Reset
Click it to rest to factory default settings.
4
4
.
.
7
7
.
.
4
4
P
P
h
h
o
o
n
n
e
e
S
S
t
t
a
a
t
t
u
u
s
s
From this page, you can find codec, connection and other important call status for each port.
Each item is explained as follows:
Item Description
Refresh
The information will update immediately when the Refresh
button is clicked.
Port
It shows current connection status for Phone(s) ports.
Status
It shows the VoIP connection status.
IDLE - Indicates that the VoIP function is idle.
HANG_UP - Indicates that the connection is not
established (busy tone).
CONNECTING - Indicates that the user is calling out.
WAIT_ANS - Indicates that a connection is launched and
waiting for remote user’s answer.
ALERTING - Indicates that a call is coming.
ACTIVE-Indicates that the VoIP connection is launched.
