Vigor2760 Series User’s Guide
122
1. Choose the profile (from SSID1 to SSID4) you want and click the check box.
2. Click Edit to open the following page.
Available parameters are listed below:
Item Description
Enable
Check the box to enable the Access Control profile.
Name
Display the name of the Access Control profile. Such name
is assigned by the router in default.
Filter Type
Allow List - The clients displayed on MAC List are allowed
to pass through the router.
Deny List – The clients displayed on MAC List are NOT
allowed to pass through the router.
MAC List
Type the MAC address of the wireless client. Click the +
button to display the entry box to fill in the MAC address.
Select – Click the button to choose the MAC address of the
wireless stations. The one selected here is allowed to access
into Internet through Vigor2760.
Apply
Click it to save the settings.
Clear
Click it to remove the modification of the web page.
