Vigor2760 Series User’s Guide
6
Interface Description
PWR Connector for a power adapter.
I / O Power switch.
Factory Reset Restore the default settings. Usage: Turn on the router (ACT LED is
blinking). Press the hole and keep for more than 5 seconds. When you see
the ACT LED begins to blink rapidly than usual, release the button. Then
the router will restart with the factory default configuration.
WLAN
ON/OFF/WPS
WLAN WPS - Press this button for 2 seconds to wait for client device making
network connection through WPS. When the LED lights up, the WPS connection
will be on.
WLAN ON/OFF - Press the button once to enable (WLAN LED on) or disable
(WLAN LED off) wireless connection.
VDSL/ADSL Connector for accessing the Internet.
USB (1-2) Connector for USB storage device (Pen Driver/Mobile HD) or printer or
3G backup.
LAN (1-4) Connectors for local network devices.
