Vigor2760 Series User’s Guide
240
Refresh
Click it to fresh the web page.
Wakeup
Click it to execute the job of wake on LAN.
Enable
Display the activation status of thee profile.
Enable – The profile is available for choosing.
Disable – The profile is not available for choosing.
To create a new profile, please do the following:
1. Click the Add button.
2. The following setting page will appear.
Available parameters are listed below:
Item Description
Enable
Check this box to enable such profile.
Name
Type a name for such profile.
Interface
The interface selected here will be used to invoke WOL
profile.
Wake by Address
The profile can be wake by using address object. Check the
To Next Page
