Vigor2760 Series User’s Guide
61
IPv4.
IPv6 – You have to type IP address based on
IPv6.
Protocol - Available protocols include Static, DHCP and
PPPoE.
When PPPoE is selected
Username - Type in the username provided by ISP in this
field.
Password - Type in the password provided by ISP in this
field.
Confirm Password - Type in the password again for
confirmation.
PPP Authentication - Select PAP only or PAP or CHAP
for PPP.
MTU - It means Max Transmit Unit for packet. The default
setting will be 1492.
PPPoE Pass-through Enable- The router offers PPPoE
dial-up connection. Besides, you also can establish the
PPPoE connection directly from local clients to your ISP via
the Vigor router. Thus, the PC can access Internet through
such direction. Check the box to enable such function.
Pass-through Interface – Specify an interface.
VLAN Encapsulation - Enable the function of VLAN with
tag. The router will add specific VLAN number to all packets
while sending them out. Please type the tag value and specify
the priority for the packets sending by the router.
VLAN ID –Type the value as the VLAN ID
number. The range is form 1 to 4000.
Priority (802.1p) - Type the packet priority
number for such VLAN. The range is from 0 to 7.
IPv4 Setting – It is available when IPv4 is selected as IP
Version.
PPP Fixed IP - Type a fixed IP address for PPP
connection.
Default Route - Check the box to enable the
default route for such WAN profile.
IPv6 Setting – It is available when IPv6 is selected as IP
Version.
Prefix Length – Type the fixed value for prefix
length.
Prefix Send To – Choose the interface (LAN).
Default Route - Check the box to enable the
To Next Page
