1.4.2 LEDs while booting
The single LED on the front panel indicate the following state and meaning during boot-
ing.
Tabelle 8:
Table 8: LEDs while booting, ENC66
LED Indication Meaning
WDOG Off Watchdog is not triggered in bootloader
CAN1/LED1 Off Not used
CAN1/LED2 Off Not used
CAN2/yellow Off Not used
CAN2/green Off Not used
RS232/green Off or flashing light RS232/TX state (indicates transmitting of data)
RS232/green Off or flashing light RS232/RX state (indicates receiving of data)
ETHERNET/yellow Flashing light Ethernet/ activity status
ETHERNET/green Off or on Ethernet/ connect status
CAN3/green Off Not used
CAN3/green Off Not used
CAN4/green Off Not used
CAN4/green Off Not used
