ECKELMANN E-Control CNC - Status in Normal Operation

18 / 97
1.4.4 Status information in normal operation
After the start of the firmware, the controller changes to normal operation.
The single segments of the 7-segment indicator are assigned to a system task each. The
brightn
ess of the various segments corresponds to the computing load of the single tasks
in the system.
The assignment is as follows:
Abbildung 2:
a
b
c
d
e
f
g
h
Figure 2: 7-Segment indicator
Tabelle 10:
Table 10: Status information in normal operation, ENC66
Segment Meaning
a PLC (PLC program)
b SRV (Services)
c AXE (fine interpolator)
d ZST (central controller)
e INT (interpreter)
f POS (interpolator)
g NET (Ethernet communication)
h (dot) Pulses in the rhythm of
interpolator
(freq=1/MK_DELTAT [Hz])
