Introduction Manual ENC66
eckelmann.de
Data block 0, 1, 2 and 8 to 15 are used differently for the controller. So the diagnostic ad-
dress can only be mapped to DB3 to DB7 (MW 768 to 2047).
You can add and configure the LBM DIM16 module in the same way. This module also uses
one input and one output word.
Abbildung 53:
Figure 53: The added LBM DIM16 module
9.5 Task configuration
A task configuration (via tab „Resources“) is only required if system variables are used by
data block _0 (For details please check /1/).
Abbildung 54:
Figure 54: Task configuration
9.6 Changing of the language german / english
A switch of the language in CoDeSys from german to english occurs by
