1.4.6 Error indication
1.4.6.1 Error indication during booting
Probable errors in the booting phase are signalled by the following indication pattern. The
in
dication shows the pattern sequentially with 2 characters/sec. The indication is made until
the controller is reset (exception: start of the boot monitor).
Tabelle 12:
Table 12: Error indication during booting, ENC66
7-segment indicator Meaning Start of boot
monitors
E01 RAM error
E02 Checksum error in boot loader (FPROM)
E05 unknown FPROM type
E06 Error during loading of firmware from FPROM x
E07 Error during start of firmware x
E88 Processor exception
A running light in the 7-segment indicator (two adjacent segments rotating in clockwise di-
rection) shows that the boot monitor is active.
The boot monitor is activated either by the user or by the boot loader, if the start of the
operating system
has not been made successfully after E06 and E07.
1.4.6.2 Error indication in normal operation
Probable errors are signalled by the following indicatio
n pattern. The indication shows the
pattern sequentially with 2 characters/sec. The indication is made until the controller is re-
set.
Tabelle 13:
7-segment
indicator
Meaning
E104 ZST / I2C initialization failed
E105 ZST / EEPROM initialization failed
E106 ZST / RTC initialization failed
E107 UTI / Power failure of real-time
clock, time invalid
E108 ZST / Identification of the ExC6
6-expansion card failed
F001 SYS / Incorrect segment at freemem()
F002 SYS / Invalid seg
ment at freemem
F003 SYS / Invalid argument at PutMsg()
F004 SYS / Unexpected termination of a task
Table 13: Error indication in normal operation, ENC66
