ECKELMANN E-Control CNC - Function Block Details; START_STOP, SIGNAL_HANDLER, M_FUNCTIONS

(* ------- checking for new M-functions -------- *)
IF (NOT DB1_NC2
SPS_MFKT_STROBE_BIT AND DB1_SPS2NC_MFKT_QUITT_BIT) THEN
CASE (DB1_N
C2SPS_MFKT_W) OF
0: M_M0_bit := TRUE; (* feedstop *)
1: M_M1_bit := DB1_NC2SPS_WAHLWEISE_HALT_BIT; (* optionally stop *)
14: M_M14_bit := TRUE; (* tool down *)
15: M_M15_bit := TRUE; (* tool up *)
30: M_M30_bit := TRUE; (* end of program *)
ELSE
mfkt_dw:=DB1_NC2SPS_MFKT_W;
SPSERROR(F_UNKNWON_MFCT_KI, 1, 'M-Fct: %lu', ADR(mfkt_dw));
END_CASE
END_IF
(* ------- executing of the M-functions ------- *)
(* feedstop *)
IF (M_M0_bit) THEN
IF (START_STOP.TRIG_STARTBUTTON.Q
OR START_STOP.TRIG_STOPBUTTON.Q)
THEN
M_M0_bit := FALSE;
END_IF
END_IF
(* optionally stop *)
IF (M_M1_bit) THEN
IF (START_STOP.TRIG_STARTBUTTON.Q
OR START_STOP.TRIG_STOPBUTTON.Q)
THEN
M_M1_bit := FALSE;
END_IF
END_IF
db2_hint_optionallystop_active_bit := M_
M1_bit;
84 / 97
Upon the recognition that the new M-function is M14 or M15, the follow-up program part
is jumped to
M14: The output O_ToolDown is set and a timer of 5s is started. If input I_ToolDown is set
after max. 5s, the function is switched, otherwise an error message occurs. The error mes-
sage is made via the function SPSERROR that opens
an error screen in the StdHMI via the
error number (F_TOOL_UP_KI).
