Menus
A menu can contain up to ten menu items (0 .. 9; 0 for menu item 10). After the selection of a menu item using
the cursor buttons ( ) and ( )andbytappingtheENTERbutton( ) or by tapping the buttons 0..9), other
submenus or operating screens are displayed.
Selection of the menu items
Each line of this selection list in the display has a digit between 1 and 9 and 0 for menu item 10 with the
associated name of the corresponding menu item. The various menu items can be selected directly by tapping
the digit buttons 0 .. 9.
If a menu provides more than 3 submenus, the cursor buttons (� ) and ( ) can be used for paging in the
menu to display the remaining menu items.
Screens
An operating screen shows values for output and/or input. There may be more values for output and/or
inputthanfitintothedisplayatonetime.Thecursorkeyscanbeusedtoscrollthroughtheseadditionalvalues.
Thescreenmayalsocontainmorethanonepage,inwhichcasethepagescanbeviewedoneatatime.
Scrolling
Using the cursor buttons ( �↑)and(�↓)
scrolling can be line by line, e.g. for selection of a variable in a line from a list of predefined variables.
scrolling can be block by block so that values can be shown that cannot be displayed with the others due
tothelimitedcapacityofthedisplay
Paging
If an operating screen contains multiple pages (e.g. the alarm list), these can be paged through using the
cursor buttons ( �←)and(→).Inmenusthatprovidemorethan3submenus,thesecanbepagedthrough
usingthecursorbuttons(↑)and(�↓)todisplaytheremainingmenuitems.
MODE + 9threelinesupwardsand
MODE + 3threelinesdownwards
A menu item can be selected by pressing the respective numeric key regardless of whether the item
itself is visible on the display.

Arrows appear on the right of the display to indicate whether you can scroll or page through a menu or
screen.

