Menu 2-4-2 Zone 2
Not used with this controller type
Menu2-4-3Zone1AAltern.
ALARM 1A POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High
Temperature alarm is generated
0..30 8 °C
Low Temp Setp. XX K Low temperature setpoint (difference below
temperature control setpoint) at which Low
Temperature alarm is generated
--, 0..6 4 K
Menu2-5FrameHeater
FRAME HTR POS: XXXXX
1 Mode altern. Move to menu 2-5-1
2 Setpoint frm htr Move to menu 2-5-2
3 Mode altern. Move to menu 2-5-3
Not shown when setpoint toggle is disabled (Menu 3-3)
4 Setpoint altern. Move to menu 2-5-4
Not shown when setpoint toggle is disabled (Menu 3-3)
Menu 2-5-1 Mode altern.
Selectbetweenvalues.Checkmarkshowscurrentsetting.
MODE POS: XXXXX Entry Default
fixed run time
Fixed frame heater on time
enthalpy-ctrl rtm Enthalpy control by ambient air temperature and
humidity
Menu2-5-2Setpointframeheater
SETPOINTS POS: XXXXX Entry Default
Mod: xxxxxxxxxxxx Displays set frame heater mode (Menu 2-5-1) Fixed on time
Run Time XXX % Fixed on time, Only shown when mode set to
Fixed On Time (Menu 2-5-1)
--, 0..100 100 %
emerg.run time XXX % On time in failure of ambient air humidity or
temperature signal (via CAN bus)
Only shown when mode set to Enthalpy Control
(Menu 2-5-1)
--, 0..100 100 %
enthalp. offs. XXX % Offset to on time with activated enthalpy control
(via CAN bus)
Only shown when mode set to Enthalpy Control
(Menu 2-5-1)
-50..50 0 %
Invert Output xxx Inversion of the function of the frame heater
output(terminal 91/92)
, , (ON/OFF)
ON
