Menu1-5Alarm
ALARM Pos: XXXXX
Alarm Relay XXX Current ON/OFF status of alarm output Terminal 15/16/18
Hi Temp Setp.1 XX °C High temperature setpoint Zone 1
Lo Temp Setp.1 XX K Low temperature setpoint Zone 1
Hi Temp Setp.2 XX °C High temperature setpoint Zone 2;Only shown when two-zone operation is set
(Menu 6-1)
Lo Temp Setp.2 XX K Low temperature setpoint Zone 2;Only shown when two-zone operation is set
(Menu 6-1)
Menu1-6PaneHeater
PANE HTR XXXXX
Pane Heater xxx Current OFF/ON status of pane heater output Terminal 73/74
Run Time xxx % Current on time of frame heater
Humidity xxx % Current ambient air humidity (transmitted via CAN bus from pack controller with fitted
ambient humidity sensor)
Room temp xx °C Current ambient air temperature (transmitted via CAN bus from pack controller with
fitted ambient temperature sensor
