Parameter List and Menu Structure of VS 300
125
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
SperrRK2 m. RK1 XXX Booster operation: disable shutdown CL2,
when compressor running in CL2 (only
shown in Superuser mode)
↑, ↓,
(ON/OFF)
OFF OFF - -
Config XXXX Controller configuration (NT/LT/HP)
(only configuarble in terminal mode and
Superuser mode)
→ See Screen 3-1-i
1)
0 to 4/8/12 depending on expansion stage and configuration
(see section 3 Function - System Configuration/Allocation of Relay/Control Stages).
2)
CL1 must not be HP controller.
3)
CL2 must not be HP controller.
4)
CL2 must be HP controller.
S Screen 3-1-a CL1 Compressors/Fans: Enable/Disable Control Stages
CL1-Comp/COND POS: XXXXX Entry
Default
NT LT HP Dim.
Stage 1
1)
XXX
Shows only relay/control stages allocated
to Control Loop 1
↑ , ↓
(ON/OFF)
ON ON ON -
...
Stage 12
1)
XXX
1)
0 to 4/8/12 depending on expansion stage and configuration (see section 3 Function - System
Configuration/Allocation of Relay/Control Stages).
