Parameter List and Menu Structure of VS 300
144
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
S Menu 6-4 Daily Operating Data CL2
HISTORY CL2 POS: XXXXX
1 Run times Next: Screen 6-4-1
2 Run times D Next: Screen 6-4-2
3 Run times N Next: Screen 6-4-3
4 Starts Next: Screen 6-4-4
5 Starts D Next: Screen 6-4-5
6 Starts N Next: Screen 6-4-6
7 Activity Next: Screen 6-4-7
8 Activity D Next: Screen 6-4-8
9 Activity N Next: Screen 6-4-9
S Menu 6-4-1 Run Times
HISTORY POS: XXXXX Entry
Date: dd.mm.yy Date ↑, ↓
R.time CL2 → Next: Screen 6-4-1-a →
↓ Select date by ↑↓, max. 31 days past ↑, ↓
S Screen 6-4-1-a Run Times CL2 Total
R.time CL2 POS: XXXXX Entry
Stage 1 hh.mm Show run times for compressor/fan stage 1
1)
↑, ↓
...
Stage 12 hh.mm Show run times for compressor/fan stage 12
1)
↑, ↓
1)
Number of relay/control stages CL1 [1..n] + Number of relays CL2 [n+1..m] + Number internal alarm relais
<= Number of relay/control stages VS 300 (max. 4, 8, 12 depending on expansion stage and configuration);
see section 4.1.1 System Configuration - Allocation of Relay/Control Stages
S Menu 6-4-2 Run Times Day
HISTORY POS: XXXXX Entry
Date: dd.mm.yy Date ↑, ↓
R.time CL2 D → Next: Screen 6-4-2-a →
↓ Select date by ↑↓, max. 31 days past ↑, ↓
