Parameter List and Menu Structure of VS 300
145
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
S Screen 6-4-2-a Run Times CL2 Day (1st Setpoint)
R.times CL2 D POS: XXXXX Entry
Stage 1 hh.mm Show run times for compressor/fan stage 1
1)
,
...
Stage 12 hh.mm Show run times for compressor/fan stage 12
1)
,
1)
Number of relay/control stages CL1 [1..n] + Number of relays CL2 [n+1..m] + Number internal alarm relais
<= Number of relay/control stages VS 300 (max. 4, 8, 12 depending on expansion stage and configuration);
see section 4.1.1 System Configuration - Allocation of Relay/Control Stages
S Menu 6-4-3 Run Times Night
HISTORY POS: XXXXX Entry
Date: dd.mm.yy Date ,
R.times CL2 N Next: Screen 6-4-3-a
Select date by ↑↓, max. 31 days past ,
S Screen 6-4-3-a Run Times CL2 Night (2nd Setpoint)
R.times CL2 N POS: XXXXX Entry
Stage 1 hh.mm Show run times for compressor/fan stage 1
1)
,
...
Stage 12 hh.mm Show run times for compressor/fan stage 12
1)
,
1)
Number of relay/control stages CL1 [1..n] + Number of relays CL2 [n+1..m] + Number internal alarm relais
<= Number of relay/control stages VS 300 (max. 4, 8, 12 depending on expansion stage and configuration);
see section 4.1.1 System Configuration - Allocation of Relay/Control Stages
