Edwards STP-iXA3306C User Manual

STP-iXA3306 Series Turbomolecular Pump
MT-82E-001-H
Page 109
5
SERIAL COMMUNICATION PROTOCOL
5.4.5 ReadModFonct
Function: Reads the pump operation mode and the errors being detected. The data of errors being
detected reads the same data as that of "ReadFailMess".
Transmission frame:
PC->SIM Stx 0 0 1 ? M Etx LRC
SIM->PC Ack
PC->SIM Ack
SIM->PC Stx 0 0 1 Sp M Parameter 1 to 82
*1
Etx LRC
Parameter Item Data format Remarks
1 Pump operation mode 8-bits hexadecimal
coded ASCII
Refer to Table 38
2 The number of error 8-bits hexadecimal
coded ASCII
Up to 80 errors
*1
3 to 82
*1
Error 1 8-bits hexadecimal
coded ASCII
*2
… …
Error 80
*1
8-bits hexadecimal
coded ASCII
*1 The maximum number of errors may differ depending upon the software version of the STP pump. It is recommended that
an application be designed as variable-length data. In Revision C, the case of the error detection is less than or equal 32
and Parameter length is 34.
*2 Value corresponding to the error message is transmitted (refer to Table 36 and Table 37). The most recent error has the
largest parameter number. When the number of errors being detected is under the maximum number, the value of
parameter that is larger than the number of errors being detected is set to 0.
