Edwards STP-iXA3306C User Manual

STP-iXA3306 Series Turbomolecular Pump
MT-82E-001-H
Page 111
5
SERIAL C
OMMUNICATION PROTOCO
L
5.4.6 ReadVersion
Function: Read the software version.
Transmission frame:
PC->SIM
Stx
0
0
1
?
V
Etx
LRC
SIM->PC
Ack
PC->SIM
Ack
SIM->PC
Stx
0
0
1
Sp
V
Parameter 1 to 24
Etx
LRC
Parameter
Item
Data format
Remarks
1 to 16
Control unit software version
8-bits hexadecimal
coded ASCII
17 to 20
Motor driver software version
4-bits ASCII character
Ver.1.2 = 0120
21 to 24
AMB software version
4-bits ASCII character
Ver.3.4 = 0340
Example:
Control unit software version
: 36335F4120312E302020202020202020
hex
= 63_A 1.0
Motor driver software version
: 0120
hex
= 1.2
DSP software version
: 0340
hex
= 3.4
Parameter
1
2
3
4
5
6
7
8
9
10
"6"
"3"
"_"
"A"
" "
"1"
"."
"0"
" "
" "
ASCII
3
6
3
3
5
F
4
1
2
0
3
1
2
E
3
0
2
0
2
0
HEX
33
36
33
33
35
46
34
31
32
30
33
31
32
45
33
30
32
30
32
30
Parameter
11
12
13
14
15
16
17
18
19
20
21
22
23
24
" "
" "
" "
" "
" "
" "
ASCII
2
0
2
0
2
0
2
0
2
0
2
0
0
1
2
0
0
3
4
0
HEX
32
30
32
30
32
30
32
30
32
30
32
30
30
31
32
30
30
33
34
30
