STP-iXA3306 Series Turbomolecular Pump

MT-82E-001-H

Page 23

INSTALLATION

3.1.2 Installation area

Leave enough space for the followings in addition to that for the STP pump: (see Figure 9)

 Space for maintenance and inspection.

 Space for connecting cables.

CAUTION

DO NOT bend the cables excessively and beware of any obstacles when installing the STP pump.

In addition, leave enough space to install other cables without bending them excessively.

Front side

Figure 9 - Space around the STP pump

150
