STP-iXA3306 Series Turbomolecular Pump

MT-82E-001-H

Page 119

SERIAL C

OMMUNICATION PROTOCO

Bit

Warning message

16-bits hex value

[System reservation]

0001

WARNING: Second Damage Limit

0002

WARNING: First Damage Limit

0004

WARNING: Imbalance X_H

0008

WARNING: Imbalance X_B

0010

WARNING: Imbalance Z

0020

WARNING: Pump Run Time Over

0040

WARNING: Pump Overload

0080

[System reservation]

0100

[System reservation]

0200

[System reservation]

0400

[System reservation]

0800

[System reservation]

1000

[System reservation]

2000

[System reservation]

4000

[System reservation]

8000

Table 40 - Warning value bit assign
