STP-iXA3306 Series Turbomolecular Pump

MT-82E-001-H

Page 40

INSTALLATION

3.4.4 Legs for securing the base

CAUTION

When securing the base, use stainless steel securing bolts with a tensile strength class is 70 or

more.

Figure 23 shows the position of the six screw holes for securing the base of the STP pump.

(A) Screw holes for securing the base

(B) Position of the screw holes

for securing the base

Figure 23 - Screw holes for securing the base

M16,

depth 30 mm
