STP-iXA3306 Series Turbomolecular Pump
MT-82E-001-H
Page 17
TECHNICAL DATA
2
2.4 Control unit
The values shown below are typical. They are not guaranteed.
Item
STP-iXA3306C/B
STP-iXA3306CV/BV
Input voltage
ACV
200 to 240
Input power
VA
1500 maximum
(without TMS unit)
1800 maximum
(with TMS unit)
Input frequency
Hz
50/60 ± 2
Leakage current
mA
2.0 maximum
Input phase
Single phase
Main fuse specification
A
10
Current Ampere Interrupting Capacity
(AIC)
A
100
(240V AC 50/60 Hz)
Pollution degree
2
Installation category
â…¡
Motor driving system
3-phase d.c. brushless motor driver
Output frequency under normal operation
Hz
462 maximum
Battery for clock function
Specification
Lithium battery (3 V, 130 mAhr)
Model
DS9034PCX
Maker
MAXIM
Panel indication LED
POWER
(Green LED)
FAILURE
(Red/Orange LED)
ROTATION
(Green/Orange LED)
Data
(Green LED)
Off-Line
(Orange LED)
Error
(Red LED)
Input/Output connector
AC POWER X11
(3 pins)
HEATER X12
(2 pins)
REMOTE X2
(37 pins)
COM1 X3
(9 pins)
COM2 X4
(9 pins)
STP-LINK X5
(8 pins)
OPTION X6
(12 pins)
