Page 115
5
SERIAL C
OMMUNICATION PROTOCO
L
Remote mode
Value
I/O Remote (X2)
1
COM1 (X3)
2
COM2 (X4)
5
COM3 (X5 STP-Link)
6
[System reservation]
3, 4
Table 39 - Remote mode
Example:
Remote mode setting
: 01
hex
= I/O Remote
TMS function setting
: 00
hex
= ENABLE
Emergency vent valve setting
: FF
hex
= DISABLE
Parameter
1
2
3
4
ASCII
0
1
0
0
*1
*1
F
F
HEX
30
31
30
30
46
46
*1 System reservation
5.4.11 ReadEvents
Function: Reads the "Error Record". It has the most recent 10 errors that have been detected.
Transmission frame:
PC->SIM
Stx
0
0
1
?
g
Etx
LRC
SIM->PC
Ack
PC->SIM
Ack
SIM->PC
Stx
0
0
1
Sp
g
Parameter 1 to 11
Etx
LRC
