STP-iXA3306 Series Turbomolecular Pump
MT-82E-001-H
Page 123
5
SERIAL C
OMMUNICATION PROTOCO
L
5.4.16 ReadOptionFunc
Function: Reads the setting value of the input operation port, warning function, and serial
communication time out.
Transmission frame:
*1
PC→SIM
Stx
0
0
1
?
=
Etx
LRC
SIM→PC
Ack
PC→SIM
*1
Ack
SIM→PC
Stx
0
0
1
Sp
=
Parameter 1 to 13
Etx
LRC
*1 The HEX code of ASCII character ' = ' is "3D".
Parameter
Item
Data format
Remarks
1
Input operation port setting
8-bits hexadecimal
coded ASCII
2
TMS Option
Enable/Disable setting
8-bits hexadecimal
coded ASCII
3
[System reservation]
48-bits hexadecimal
coded ASCII
4
Second Damage Limit Option
Enable/Disable setting
8-bits hexadecimal
coded ASCII
5
First Damage Limit Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
6
Pump Runtime Over Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
7
Pump Runtime Over Warning
Hours setting (×100 hours)
32-bits hexadecimal
coded ASCII
8
Imbalance Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
9
Pump Overload Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
10
Pump Overload Warning
Motor current setting
16-bits hexadecimal
coded ASCII
0.1 % step
11
Pump Overload Warning
Rotational speed setting
16-bits hexadecimal
coded ASCII
0.1 % step
