STP-iXA3306 Series Turbomolecular Pump

MT-82E-001-H

Page 50

INSTALLATION

3.9.2 Configuration of the STP pump with the TMS

Figure 29 shows wiring and piping of two-way valve type. Refer to Figure 30 for wiring and piping of

three-way valve type.

STP pump

TMS heater cable

TMS heater (Built-in)

TMS valve cable

TMS valve

Power cable

Control unit

Figure 29 - Configuration of the TMS
