STP-iXA3306 Series Turbomolecular Pump

MT-82E-001-H

Page 19

TECHNICAL DATA

2.5 External appearance of the STP pump

Inlet port

flange

VG250

ISO250F

VG300

VG350

ISO320F

ICF305

VG350

ICF356

φA

350

335

400

450

425

305

450

356

φB

358

28.5

281

242

308

242

286

308

281

435

396

440

396

435

363

325

368

325

364

320

282

281

282

325

281

321

319

281

324

281

320

251

212

256

212

251

Figure 7 - External appearance of STP-iXA3306C(V)/iXA3306B(V)

No.

Item

Description

Height of water cooling

port (IN)

Rc1/4

Control unit

Height of the purge port

Outlet port flange

KF40

Screw hole for securing

the base

6-M16

depth 30

Purge port

KF10

Cooling water port

2-Rc1/4

Height of water cooling

port (OUT)

Rc1/4

Declaration of Conformity2
