Integrating the Fiery ES into your network
Your service technician ensures that the Fiery ES is correctly installed at your site, the power supply and cooling are
adequate, and the required cables are connected.
Fiery ES hardware description
This section provides illustrations for the Fiery ES.
Front and back panels
Following are illustrations of the connector and LED panels.
Figure 1: Fiery ES front panel
Configuration and Setup
Integrating the Fiery ES into your network
