7 Select Create a new port, select Standard TCP/IP Port from the Type of port menu, and then click Next.
Note: The WSD port is supported on Windows 7 or later.
8
Do one of the following:
• Windows 10/Server 2016: Type the host name or IP address of the Fiery ES. Select the Query the printer and
automatically select the driver to use check box. Click Next and proceed to step 9.
• Windows 8.1/Server 2012 R2: Type the host name or IP address of the Fiery ES. Select the Query the printer
and automatically select the driver to use check box. Click Next and proceed to step 9.
•
Windows 7/Server 2008 R2: Type the host name or IP address of the Fiery ES, and then click Next. Proceed to
step 9.
9 In the Printers box, select your printer and click Next.
Note: Select the printer driver with "US" for North America (the default document size is Letter) or without "US"
for International (the default document size is A4).
10 Type a name for the Fiery ES in the Printer name field, and click Next.
This name is used in the Devices and Printers (or Printers and Faxes or Printers) folder and the queues window.
11
Follow the on-screen instructions.
Indicate whether you want to make it the default printer. Do not share the printer and do not print a Test Page at
this time.
Continue with the printer driver installation and at the last screen, click Finish.
The necessary files are installed on your hard disk drive.
12
Configure the installable options.
For more information, see Configure installable options on Windows client computers on page 23.
13
To set up a connection other than Port 9100, see Set up Standard TCP/IP Port (Raw or LPR) printing
connections on Windows client computers on page 18.
14 To use the printer driver, you must select the following options on the Advanced tab of the printer driver:
• Spool print documents so program finishes printing faster
• Start printing immediately
• Print spooled documents first
15 Click Apply in the Fiery ES Properties dialog box, and then click OK.
Install and connect to a virtual printer
A virtual printer allows you to print to the Fiery ES using a predefined set of job settings.
You do not have to set print options manually. Before you can print to a virtual printer, the administrator must
create and configure the virtual printer using Command WorkStation. After the virtual printer is set up, you can
install the printer driver and printer description files on your computer from the Fiery ES using Point and Print.
For more information about setting up virtual printers, see Command WorkStation Help.
Printing
Windows for Fiery ES
13
