Titanium Interfaces User Guide
lvds_rule_clkout_mode (error)
Message Serial clock name must be configured in clock output mode
To fix When you are using the LVDS serializer (serialization width greater than 1), you need to
specify the serial clock pin name.
Message Parallel clock name must be configured in clock output mode
To fix When you are using the LVDS serializer (serialization width greater than 1), you need to
specify the parallel clock pin name.
Message Clock output mode is not supported with serialization width 1
To fix When you set the serialization width to 1, you are bypassing the serializer and using the block
as a simple buffer. As a simple buffer, you cannot use the block as a reference clock output.
Change the serialization width.
Message Clock output mode is not supported with serialization disabled
To fix If you turn off Enable Serialization, you are bypassing the serializer and using the block as a
simple buffer. As a simple buffer, you cannot use the block as a reference clock output. Turn
on Enable Serialization and set the serialization width.
lvds_rule_deserial_rate (error)
Message Half rate deserialization only allowed with even deserialization width
To fix When you turn on Enable Half Rate Serialization, you can only use an even number for the
deserialization width. Change the width to an even number or turn the option off.
lvds_rule_output_mode (error)
Message Instance of LVDS Tx has invalid configuration
To fix The block settings are not correct. It might be best to remove the block and start over :)
Message Output name must be configured in data output mode
To fix Specify a valid pin name.
Message Parallel clock name must be configured in data output mode
To fix When you are using the LVDS serializer (serialization width greater than 1), you need to
specify the parallel clock pin name.
Message Serial clock name must be configured in data output mode
To fix When you are using the LVDS serializer (serialization width greater than 1), you need to
specify the serial clock pin name.
lvds_rule_resource (error)
Message Resource name is empty
Resource <string> is not a valid LVDS device instance
To fix You need to choose a valid resource.
