Chapter2 Setup

Setup

This chapter describes procedures for installing and setting up the printer that are required before using the

printer.

Unpacking

After unpacking, make sure that all the printer and the accessories are included and they have no damages.

The included items are as follows.

1 Printer (CW-C6500 Series) 2 Ink Cartridges C, M, Y, BK (For initial charging)

3 Roll paper (for initial operation check) 4 Flange and Spindle

5 Power cable 6 USB cable

7CD-ROM 8Manual

9 Power cable for specific regions (not included

depending on country or region)

Before Use3
