54
Chapter2 Setup
How to Load Paper (Peeler Model - Supply from Inside)
1
Turn on the printer, and then check that [Internal] is selected as the [Media Source]
setting on the operation panel.
("Operation Panel Settings" on page 145)
2
Open the paper cover
3
Remove the spindle from the printer.
As shown in the figure, hold the spindle and flange with both hands, and remove them.
4
Load the roll paper on the spindle and fix it with the flange.
• To move the flange, squeeze the two levers.
• When loading the roll paper on the spindle, take note of the winding direction. The correct wind-
ing direction is marked on the spindle.
• Fix the flange and roll paper so that there is no gap in between.
To Next Page
