Epson TM-C3500 User Manual

121
How to Adjust the Cut Position
Adjust the cut position to match the media form used.
When using media with a perforated line, adjust the cut position so that the perforated line is
not cut.
Media Form Description
Die-cut label (Gap)
• When the adjustment value is +, the cut position moves closer to the
reference position (print start position).
• When the adjustment value is –, the cut position moves away from the
reference position (print start position).
Backing paper
Label
Label
Refer
ence position
(print start position)
Cut position
Printable area
Paper feed
direction
Downloaded from ManualsNet.com search engine

Epson TM-C3500 Specifications

General

Print Resolution	720 x 360 dpi
Ink Colors	Cyan, Magenta, Yellow, Black
Ink Cartridges	Individual ink cartridges
Color	Yes
Print Speed	Up to 103 mm/sec
Media Types	Roll paper, Fanfold paper
Interface	USB, Ethernet
Dimensions	310 x 283 x 261 mm
Weight	12 kg
Cutter	Auto cutter
Media Width	25 - 112 mm
