8.5.6 CBAC150-2m5 Cable
Fig. 8-11 CBAC150-2m5 Cable
8.6 CAN Terminating Resistor
Fig. 8-12 CBCX131-0 Terminating Resistor
Order Name Short Name Order
Number
CAN Interface Cable, OBDII J1962 Lemo
1B FGC (16mc-8mc), 2m5
CBAC150-2m5 F 00K 104 159
Order Name Short Name Order
Number
CAN 120 & Termination Resistor, 2xDSUB
(9fc+9mc)
CBCX131-0 F 00K 103 786
5
4
3
2
1
6
7
8
9
5
4
3
2
1
9
8
7
6
120 Ohm
